RAYS A-LAP-07X Forged 1-Piece Wheel

SKU: 10096552015BD

RAYS A-LAP-07X Forged 1-Piece Wheel

$394.64 $510.71 Save $116.07

Shipping calculated at checkout

Size | Offset: 16x5.5J +20
PCD: 5x139.7
Color: Black/Rim DC (BD)



RAYS A-LAP-07X — Forged 1-Piece Wheel | Size Chart

Forged 1-piece construction (18-inch sizes use a reverse rim). INSET / P.C.D. / HUB BORE shown in mm.

Size Face Inset Hole P.C.D. Hub Bore Drill Color Code
16-inch
16x5.5J F2 +20 5 139.7 108.8 29-15 BD 10096552015BD
16x5.5J F2 +20 5 139.7 108.8 29-15 BR 10096552015BR
16x6J F3 -5 5 139.7 108.8 29-15 BD 10096606515BD
16x6J F3 -5 5 139.7 108.8 29-15 BR 10096606515BR
16x7J F1 +40 5 114.3 73.1 29-13 BD 10096704005BD
16x7J F1 +40 5 114.3 73.1 29-13 BR 10096704005BR
16x7J F2 +32 5 114.3 73.1 29-13 BD 10096703205BD
16x7J F2 +32 5 114.3 73.1 29-13 BR 10096703205BR
17-inch
17x6.5J F1 +38 6 139.7 112 29-15 BD 10097653816BD
17x6.5J F1 +38 6 139.7 112 29-15 BR 10097653816BR
17x7J F1 +38 5 114.3 73.1 29-15 BD 10097703895BD
17x7J F1 +38 5 114.3 73.1 29-15 BR 10097703895BR
17x8J F2 +46 6 139.7 112 29-15 BD 10097804616BD
17x8J F2 +46 6 139.7 112 29-15 BR 10097804616BR
17x8J F2 +35 5 114.3 73.1 29-15 BD 10097803595BD
17x8J F2 +35 5 114.3 73.1 29-15 BR 10097803595BR
17x8J F2 +20 6 139.7 112 29-15 BD 10097802016BD
17x8J F2 +20 6 139.7 112 29-15 BR 10097802016BR
17x8J F3 0 6 139.7 112 29-15 BR 10097800016BR
17x8.5J F2 +10 6 139.7 112 29-15 BD 10097851016BD
18-inch (Reverse Rim)
18x7J F1 +8 5 139.7 108.8 29-15 BD 10098700815BD
18x7J F1 +8 5 139.7 108.8 29-15 BR 10098700815BR
18x7J F2 -2 5 139.7 108.8 29-15 BD 10098706215BD
18x7J F2 -2 5 139.7 108.8 29-15 BR 10098706215BR
18x8J F0 +38 6 139.7 112 29-15 BD 10098803816BD
18x8J F0 +38 6 139.7 112 29-15 BR 10098803816BR
18x8J F0 +20 6 139.7 112 29-15 BD 10098802016BD
18x8J F0 +20 6 139.7 112 29-15 BR 10098802016BR
18x8.5J F0 +44 6 139.7 112 29-15 BD 10098854416BD
18x8.5J F0 +44 6 139.7 112 29-15 BR 10098854416BR
18x9J F0 +19 6 139.7 112 29-15 BD 10098901916BD
18x9J F0 +19 6 139.7 112 29-15 BR 10098901916BR
18x9J F2 0 6 139.7 112 29-15 BR 10098900016BR
18x9J F2 -20 6 139.7 112 29-15 BD 10098908016BD

* BD = Black/Rim DC  |  BR = Bronze (Anodized) (RAYS factory color codes).
* 16x6J and 18x9J -20 fitments are subject to longer lead times depending on production lot.

Available Now!
