TE37 Ultra LARGE P.C.D. Forged Wheels

SKU: 05128803616MM

TE37 Ultra LARGE P.C.D. Forged Wheels

$708.43 $895.71 Save $187.28

Shipping calculated at checkout

Size: 18x8J +36 (6x139.7)
Color: MM
MM
BR

VOLK RACING TE37 Ultra LARGE P.C.D.

All Sizes / All Colors / All PCDs — MM / BR

Overview

The TE37 Ultra LARGE P.C.D. is a forged monoblock wheel from RAYS developed for large P.C.D. applications such as trucks, SUVs, and off-road performance vehicles.

  • 1-piece forged construction (Made in Japan)
  • TE37 6-spoke design for large P.C.D. applications
  • Available PCDs: 6×139.7 / 5×150
  • Colors: MM / BR (select from variants)

6×139.7 Sizes (MM / 112 Hub Bore)

Select your Size and Color from the variant options above. The reference table below shows official RAYS specifications and codes.

Size Face Inset PCD Hub Bore Color RAYS Code
18×8J F1 +36 6×139.7 112 MM 05128803616MM
18×8J F2 +20 6×139.7 112 MM 05128802016MM
18×8J F3 +0 6×139.7 112 MM 05128800016MM
18×8.5J F1 +52 6×139.7 112 MM 05128855216MM
18×8.5J F1 +44 6×139.7 112 MM 05128854416MM
18×9J F2 +50 6×139.7 112 MM 05128905016MM
18×9J F3 +15 6×139.7 112 MM 05128901516MM
20×8.5J F0 +45 6×139.7 112 MM 05120854516MM
20×8.5J F2 +20 6×139.7 112 MM 05120852016MM
20×9J F0 +53 6×139.7 112 MM 05120905316MM
20×9.5J F2 +20 6×139.7 112 MM 05120952016MM
20×9.5J F3 +0 6×139.7 112 MM 05120950016MM

Back to top ↑

6×139.7 Sizes (BR / 112 Hub Bore)

The table below shows the same 6×139.7 size lineup in BR.

Size Face Inset PCD Hub Bore Color RAYS Code
18×8J F1 +36 6×139.7 112 BR 05128803616BR
18×8J F2 +20 6×139.7 112 BR 05128802016BR
18×8J F3 +0 6×139.7 112 BR 05128800016BR
18×8.5J F1 +52 6×139.7 112 BR 05128855216BR
18×8.5J F1 +44 6×139.7 112 BR 05128854416BR
18×9J F2 +50 6×139.7 112 BR 05128905016BR
18×9J F3 +15 6×139.7 112 BR 05128901516BR
20×8.5J F0 +45 6×139.7 112 BR 05120854516BR
20×8.5J F2 +20 6×139.7 112 BR 05120852016BR
20×9J F0 +53 6×139.7 112 BR 05120905316BR
20×9.5J F2 +20 6×139.7 112 BR 05120952016BR
20×9.5J F3 +0 6×139.7 112 BR 05120950016BR

Back to top ↑

5×150 Sizes (MM / 114 Hub Bore)

This specification is available in 20×9.5J +55 for 5×150 applications.

Size Face Inset PCD Hub Bore Color RAYS Code
20×9.5J F1 +55 5×150 114 MM 05120955518MM

Back to top ↑

5×150 Sizes (BR / 114 Hub Bore)

The same 5×150 specification is also available in BR.

Size Face Inset PCD Hub Bore Color RAYS Code
20×9.5J F1 +55 5×150 114 BR 05120955518BR

Back to top ↑

Important Notes

  • Availability must be confirmed before ordering. Some sizes may be in stock, but many are built-to-order.
  • Built-to-order: typical lead time is 2–5 months depending on production status and availability.
  • Center caps and accessories may vary by application. Please confirm before ordering if needed.
  • Size, inset, and vehicle fitment must be confirmed on the customer’s side. We can help review fitment, but final confirmation is the customer’s responsibility.
  • Shipping: international shipping available (ships from Japan).

Note: Price is for one wheel. For a full set, select quantity 4.

Need a different wheel or fitment? Contact us and we’ll help with a special order.
