RAYS BOLT & NUT HUBRING SET

SKU: 61010000008BK

RAYS BOLT & NUT HUBRING SET

$135.71

Shipping calculated at checkout

Set: No.8 BOLT & HUBRING 20P SET
Color: Black (BK)



RAYS hub-ring sets combine the bolts or nuts, the long adapter and a matched RHCS aluminium hub ring in one part number, so the wheel is centred on the vehicle hub as well as correctly fastened. Built for Toyota and Lexus P.C.D. 120 and 114.3 applications.

Features

  • All bolts supplied in these sets have a 60° taper seat
  • Do not fit to wheels with a round (spherical) seat
  • Available in Black (BK) and Chrome (CP)
  • Hub rings supplied are the RHCS aluminium type
  • 20-piece sets, supplied with the matched hub ring

Set Contents and Sample Fitment

CODE NO. PARTS SAMPLE FITMENT
61010000008BK/CP No.8 17HEX Bolt (L28 M14x1.5), Long Adapter (17/17 No.3), Hubring 72.5x60.1 TOYOTA/LEXUS P.C.D. 120, 72.5 WHEEL for BOLT
61010000010BK/CP No.9 19HEX Nut (L33 M14x1.5), Long Adapter (L80 No.2), Hubring 72.5x60.1 TOYOTA/LEXUS P.C.D. 120, 72.5 WHEEL for NUT
61010000013BK/CP No.10 17HEX Bolt (L28 M14x1.5), Long Adapter (17/17 No.3), Hubring 73.1x60.1 TOYOTA/LEXUS P.C.D. 114.3, 73.1 WHEEL for BOLT

Notes

Genuine RAYS part, shipped worldwide from Japan. Supplier-stock items may require additional lead time — contact us before ordering if you need a delivery date.

Available Now!
